CRUISE REPORT
Cruise Number: MF00-01
FOCI Number: FOCI 0MF00
Ship: NOAA Ship MILLER FREEMAN
Area of Operations:
Bering Sea
Itinerary:
Dutch Harbor, Alaska February 17, 2000
Dutch Harbor, Alaska February 25, 2000
Participating Organizations:
NOAA Pacific Marine Environmental Laboratory (PMEL)
NOAA Alaska Fisheries Science Center (AFSC)
University of Alaska Fairbanks (UAF)
Chief Scientist:
Carol DeWitt, PMEL
Personnel:
Chris Baier, AFSC
Lisa Britt, AFSC
Sigrid Salo, PMEL
Stacy Smith, UAF
Loren Tuttle, AFSC
Objectives of Cruise:
Continue acquisition of long-term biological and physical time series
Recover and deploy moorings at FOCI site 2 and site 3 Deploy satellite-tracked
drifting buoys
Summary of Operations:
CTD casts: 43
Bongos, 60 cm: 14
Bongos, 20 cm: 4
CalVET: 6
Ring.8m: 6
Mooring deployments: 1
Mooring recoveries: 2
Satellite-tracked buoy deployment: 2
Samples Collected:
Chlorophyll samples: 101
Lugols samples: 3
Microzooplankton samples: 6
Nutrient samples for Terry Whitledge (UAF): 173
Nutrient samples: 31
Quantitative tow samples: 28
Samples for NMML: 3
Zooplankton collected for stable isotope analysis (Stacy Smith - UAF):
8
Summary of Cruise:
After departure from Dutch Harbor, we steamed to site 2, in the Middle
Shelf Domain. We recovered one UAF sediment trap mooring, F-99BSST-2F,
and deployed one subsurface mooring, F-00BS-2A. The scheduled deployment
of a UAF sediment trap mooring, F-00BSST-2S, at this site was canceled
due to an air cargo delivery failure. Special thanks go to ET Scott Furnish
for his efforts to create, without a schematic, a cable required for the
sediment trap deployment - unfortunately the cable turned out to include
a tattletale which required parts that were unavailable on the ship. A
CTD cast (nutrients, chlorophylls), bongo tow, live tow and triplicate
CalVET tows were taken at this station. A CTD cast (nutrients, chlorophyll)
and bongo tow were completed at each of the four stations surrounding site
2. We proceeded along the cross-shelf line, completing the four CTD stations
(nutrients). At site 3, we completed a CTD cast (nutrients, chlorophylls)
and bongo tow. We then recovered a UAF sediment trap mooring. The scheduled
deployment of the UAF sediment trap mooring at this site was also canceled.
Triplicate CalVET tows, a single bongo tow and a CTD cast (nutrients, chlorophylls)
were completed at the center station at site 3. A CTD cast (nutrients,
chlorophylls), bongo tow, and live tow were complete at the north and south
site 3 stations. A CTD cast (nutrients, chlorophylls) and bongo tow was
completed at the western site 3 station. CTD casts were completed along
the outer shelf line. At the shelf break, a CTD cast (nutrients, chlorophylls)
and bongo tow were completed at the 200m, 500m and 1000m stations. Due
to escalating problems with the port winch, CTD operations were switched
to the port side. Thirteen CTD casts were completed using the starboard
winch. It should be noted that CTD operations on the port side are not
ideal due to the limited space available during recovery operations and
due to the limited amount of wire on the port winch.
After the 1000m station, CTD casts were completed along the "L",
heading towards site 6. At site 6, a satellite-tracked drifter (S/N 29057)
was deployed. After completing the "L", we proceeded to the easternmost
CTD line south of Amukta Pass. After the first two CTD casts were completed
on this line, we were able to switch CTD operations to the port winch.
Due to the Engineering departments efforts, the port winch had been
repaired and all CTD cast depth requirements were met. After the third
CTD on this line, operations were stopped for approximately two hours due
to weather conditions. We then were able to complete the remaining CTD
stations on this line. Due to time considerations, we were not able to
proceed to the westernmost CTD line south of Amukta Pass. We decided to
proceed to Unimak Pass deploying a satellite-tracked drifter (S/N
20932), north of Dutch Harbor, along the way. The first easternmost-
station at Unimak Pass, was crowded with fishing vessels and fishing pots
causing us to cancel the bongo operations. A CTD cast (nutrients,
chlorophylls) was completed at the first two stations. At the second station,
the weather declined and combined with the currents caused
the bongo wire to increase dramatically. This combined with the slope of
the ocean bottom caused the bongo to hit the bottom although the
bottom depth under the ship was 14 m deeper than the depth of the Seacat.
This bongo tow was unusable and bongo operations were canceled after this
station. After the next two CTD (nutrients, chlorophylls) stations across
the Pass were completed, we proceeded to Dutch Harbor.
Specifics of operations:
Date |
Time (GMT) |
Activity |
Latitude |
Longitude |
Depth |
2/18/00 |
23:31 |
Mooring recovery F-99BSST-2F |
56 52.62 N |
164 03.06 W |
74 m |
2/19/00 |
1:43 |
Mooring deployment F-00BS-2A |
56 52.61 N |
164 03.36 W |
73 m |
2/19/00 |
2:02 |
CTD 1 |
56 52.60 N |
164 03.17 W |
74 m |
2/19/00 |
2:29 |
LIVE TOW |
56 52.73 N |
164 02.78 W |
74 m |
2/19/00 |
2:41 |
LIVE TOW |
56 52.90 N |
164 02.58 W |
74 m |
2/19/00 |
2:53 |
CalVET |
56 53.06 N |
164 02.37 W |
73 m |
2/19/00 |
3:03 |
CalVET |
56 53.23 N |
164 02.19 W |
74 m |
2/19/00 |
3:11 |
CalVET |
56 53.41 N |
164 02.09 W |
74 m |
2/19/00 |
3:31 |
BONGO |
56 52.66 N |
164 02.99 W |
73 m |
2/19/00 |
4:35 |
CTD 2 |
56 56.61 N |
163 50.22 W |
71 m |
2/19/00 |
4:56 |
BONGO |
56 56.64 N |
163 49.60 W |
71 m |
2/19/00 |
5:15 |
BONGO (re-do) |
56 56.57 N |
163 49.98 W |
72 m |
2/19/00 |
7:09 |
CTD 3 |
56 39.93 N |
163 52.15 W |
77 m |
2/19/00 |
7:28 |
BONGO |
56 40.16 N |
163 52.34 W |
77 m |
2/19/00 |
9:12 |
CTD 4 |
56 45.84 N |
164 20.36 W |
75 m |
2/19/00 |
9:33 |
BONGO |
56 45.73 N |
164 20.51 W |
74 m |
2/19/00 |
11:20 |
LIVE TOW |
57 00.88 N |
164 13.23 W |
70 m |
2/19/00 |
11:30 |
LIVE TOW |
57 00.98 N |
164 13.22 W |
70 m |
2/19/00 |
11:51 |
CTD 5 |
57 01.20 N |
164 13.67 W |
70 m |
2/19/00 |
12:11 |
BONGO |
57 01.01 N |
164 13.37 W |
70 m |
2/19/00 |
14:52 |
CTD 6 |
56 37.97 N |
164 35.68 W |
78 m |
2/19/00 |
16:41 |
CTD 7 |
56 30.65 N |
165 00.06 W |
82 m |
2/19/00 |
18:23 |
CTD 8 |
56 23.48 N |
165 23.07 W |
87 m |
2/19/00 |
20:05 |
CTD 9 |
56 16.40 N |
165 46.43 W |
95 m |
2/19/00 |
21:36 |
CTD 10 |
56 10.21 N |
166 05.40 W |
106 m |
2/19/00 |
22:00 |
BONGO |
56 10.12 N |
166 06.18 W |
107 m |
2/19/00 |
23:26 |
Mooring recovery F-99BSST-3F |
56 02.97 N |
166 19.85 W |
122 m |
2/20/00 |
0:11 |
BONGO |
56 02.71 N |
166 21.14 W |
123 m |
2/20/00 |
0:32 |
CalVET |
56 03.31 N |
166 20.05 W |
122 m |
2/20/00 |
0:39 |
CalVET |
56 03.26 N |
166 19.99 W |
123 m |
2/20/00 |
0:46 |
CalVET |
56 03.23 N |
166 19.95 W |
121 m |
2/20/00 |
1:14 |
CTD 11 |
56 03.52 N |
166 19.91 W |
122 m |
2/20/00 |
3:00 |
CTD 12 |
56 12.67 N |
166 29.91 W |
115 m |
2/20/00 |
3:24 |
BONGO |
56 12.52 N |
166 29.99 W |
114 m |
2/20/00 |
3:43 |
LIVE TOW |
56 12.44 N |
166 30.18 W |
115 m |
2/20/00 |
6:21 |
CTD 13 |
55 55.12 N |
166 10.16 W |
123 m |
2/20/00 |
6:51 |
BONGO |
55 55.09 N |
166 09.72 W |
124 m |
2/20/00 |
7:08 |
LIVE TOW |
55 54.71 N |
166 09.99 W |
123 m |
2/20/00 |
8:54 |
CTD 14 |
55 58.82 N |
166 35.14 W |
131 m |
2/20/00 |
9:16 |
BONGO |
55 58.57 N |
166 35.91 W |
130 m |
2/20/00 |
10:43 |
CTD 15 |
55 54.15 N |
166 54.24 W |
134 m |
2/20/00 |
12:26 |
CTD 16 |
55 46.17 N |
167 09.79 W |
136 m |
2/20/00 |
14:27 |
CTD 17 |
55 39.13 N |
167 29.85 W |
137 m |
2/20/00 |
16:14 |
CTD 18 |
55 33.07 N |
167 45.80 W |
139 m |
2/20/00 |
18:15 |
CTD 19 |
55 26.13 N |
168 03.83 W |
199 m |
2/20/00 |
18:43 |
BONGO |
55 25.60 N |
168 04.30 W |
224 m |
2/20/00 |
20:08 |
CTD 20 |
55 22.59 N |
168 11.33 W |
525 m |
2/20/00 |
20:45 |
BONGO (wrong depth) |
55 22.16 N |
168 12.71 W |
879 m |
2/20/00 |
21:24 |
BONGO |
55 22.43 N |
168 11.71 W |
568 m |
2/20/00 |
22:36 |
BONGO |
55 21.56 N |
168 13.97 W |
|
2/21/00 |
0:09 |
BONGO |
55 21.73 N |
168 13.74 W |
1026 m |
2/21/00 |
3:49 |
CTD 21 |
55 22.36 N |
168 15.24 W |
944 m |
2/21/00 |
7:13 |
CTD 22 |
55 06.98 N |
168 29.72 W |
1726 m |
2/21/00 |
10:15 |
CTD 23 |
54 58.22 N |
168 45.66 W |
2010 m |
2/21/00 |
14:12 |
CTD 24 |
54 39.69 N |
169 12.62 W |
1726 m |
2/21/00 |
18:31 |
CTD 25 |
54 19.53 N |
169 50.23 W |
1858 m |
2/21/00 |
18:46 |
CTD 25 |
54 19.36 N |
169 50.33 W |
1858 m |
2/21/00 |
22:16 |
CTD 26 |
54 02.21 N |
169 34.74 W |
1810 m |
2/22/00 |
1:38 |
CTD 27 |
53 47.26 N |
169 16.44 W |
1547 m |
2/22/00 |
4:35 |
CTD 28 |
53 36.70 N |
169 03.42 W |
1652 m |
2/22/00 |
7:00 |
CTD 29 |
53 31.07 N |
168 54.98 W |
1820 m |
2/22/00 |
9:05 |
CTD 30 |
53 26.31 N |
168 45.06 W |
1035 m |
2/22/00 |
9:41 |
DEPLOY ARGOS BUOY 29057 |
53 26.51 N |
168 44.99 W |
984 m |
2/22/00 |
10:29 |
CTD 31 |
53 22.00 N |
168 41.70 W |
471 m |
2/22/00 |
20:39 |
CTD 32 |
52 28.48 N |
170 33.77 W |
312 m |
2/22/00 |
23:23 |
CTD 33 |
52 19.67 N |
170 31.35 W |
534 m |
2/23/00 |
2:37 |
CTD 34 |
52 10.95 N |
170 31.62 W |
1848 m |
2/23/00 |
6:32 |
CTD 35 |
52 07.28 N |
170 27.52 W |
|
2/23/00 |
10:43 |
CTD 36 |
51 53.93 N |
170 22.42 W |
182 m |
2/23/00 |
15:34 |
CTD 37 |
51 45.26 N |
170 20.94 W |
|
2/23/00 |
19:48 |
CTD 38 |
51 31.53 N |
170 13.13 W |
247 m |
2/24/00 |
0:25 |
CTD 39 |
51 13.47 N |
170 06.95 W |
279 m |
2/25/00 |
6:14 |
CTD 40 |
54 27.25 N |
165 00.46 W |
56 m |
2/25/00 |
7:14 |
CTD 41 |
54 25.01 N |
165 08.25 W |
138 m |
2/25/00 |
7:45 |
BONGO |
54 24.61 N |
165 07.47 W |
132 m |
2/25/00 |
9:07 |
CTD 42 |
54 22.63 N |
165 16.16 W |
167 m |
2/25/00 |
10:21 |
CTD 43 |
54 20.13 N |
165 24.96 W |
137 m |
